Profile Your Laser & Telecom Beams
ISO 11146 compliant, USB 2.0, Port-powered Solutions for R&D, QA & Test
Find your solution - view our Selection Guide or Product Comparison, email, or call 1-866-946-2263 x701
Questions? Call 1-866-WinCamD x701 (1-866-946-2263) or email sales@dataray.com.
In a rush? Call or order online within North America. Next-day shipping on in-stock orders received before midday PST.
|
|
Advantages
HyperCalTM real-time baseline to <0.1%.
High frame rates, up to 15 Hz at 16 bits
Multi-beam simultaneous processing
3.2 µm smallest pixel option (XHR versions)
SNR = 1,000, 25,000:1 auto-exposure
Pulsed laser Auto-capture & Ext. sync
1310 nm & NIR options for C & L telecom
M2 measurement (with accessories)
Products
BladeCam-XHR 3.2 µm pixel,6.6 x 4.9 mm, CW
WinCamD-XHR 3.2 µm pixel, 6.6 x 4.9 mm, CW
WinCamD-UCD15 4.4 µm pixel, 7.1 x 5.4 mm
WinCamD-UCD12 4.65 µm pixel, 6.3 x 4.8 mm
BladeCam-HR 5.2 µm pixel, 6.6 x 5.3 mm, CW
WinCamD-UHR 5.2 µm pixel, 6.6 x 5.3 mm, CW
WinCamD-UCD23 6.45 µm pixel, 8.8 x 6.6 mm
TaperCamD-UCD12 11 µm pixel, 14 x 10 mm
TaperCamD20-15-UCD23 15 µm pixel, 20 x 15 mm
WinCamD-FIR2-16-HR 17 µm pixel, 640 x 480, 2-16 µm
|
Advantages
Real-time XY & XYZΘΦ scanning slit profiling
0.1 micron resolution on CW lasers
UV to 4 micron wavelength options
Real-time alignment update rate
M2 measurement (built-in or with accessories)
Products
Beam'R2
2.5 & 25 µm slits, accurate & economical
Knife-Edge options for small beams
0.5 micron to 4 mm beam dimensions
BeamMap2
Patented multi-plane profiling
XYZ profiles and centroids of waists 0.5 to 200 µm
Θ, Φ, Collimation, Divergence, Pointing
Centroid, Profiles, Alignment, Divergence, M2
BeamScope-P8
Beams > 100 µm Φ
Versatile, user configurable slits & pinholes
|
